SSC Series
Product Type
Heat Exchanger
Solution
Hydraulic Oil Cooling, Compressed Air Cooling
Application
Industrial Applications
Technology
Shell & Tube, Stainless Steel
All-316 Stainless Steel Shell & Tube Oil Cooler — For Corrosive or Poor-Quality Water
The Thermal Transfer Products SSC Series is an all-316 stainless steel shell and tube heat exchanger for oil-to-water and water-to-water cooling in demanding environments. Every wetted component — tubes, tubesheets, shell, shell connections, baffles, and end bonnets — is 316/316L stainless steel, making the SSC the right choice where corrosive process fluids, saltwater, or poor-quality cooling water would quickly degrade a standard steel or brass cooler.
It uses the same proven fixed-tubesheet design as TTP’s HC Series, so it keeps the cost-effectiveness of a highly standardized product while still supporting a wide range of options for specific applications. Custom, application-specific units are also available, and the fixed-tubesheet design is a drop-in replacement for BASCO Series “500S” stainless steel units.
Maximum operating pressure is 300 PSI on the shell side and 150 PSI on the tube side, with a maximum operating temperature of 300°F. TTP’s XSelector® sizing program — available online and as a mobile app — helps select the right model for your flow, heat load, and cooling-water conditions.
Consult catalog for additional sizes and technical information.
Product Features
- Type 316 stainless steel construction
- Custom designs available
- Competitively priced
- NPT, SAE, SAE flange, or BSPP shell side connections available
- End bonnets removable for servicing
- Mounting feet included (may be rotated in 90° increments)
- Special ASME/TEMAC/CRN ratings available
| Ratings | |
|---|---|
| Maximum Operating Pressure | Shell Side 300 PSI Tube Side 150 PSI |
| Maximum Operating Temperature | 300°F |
| Materials | |
|---|---|
| Tubes | 316 stainless steel |
| Tubesheets | 316L stainless steel |
| Shell | 316L stainless steel |
| Shell Connections | 316L stainless steel |
| Baff les | 316 stainless steel |
| End Bonnets | 316 stainless steel |
| Mounting Brackets | Mild steel |
| Gaskets | Nitrile rubber/cellulose fiber |
| Nameplate | Aluminum foil |
| Configuration | |
|---|---|
| Shell side connection options | NPT, SAE, SAE flange, or BSPP |
| Mounting feet included (may be rotated in 90° increments) | |
- All catalog product is available with short lead-times
- Expert application engineers are available to select and size the right product for your application
- XSelector®* is a great tool for optimizing the sizing of TTP coolers. Check out the Apple and Android app stores to download the XSelector® App
- Our distributor One Status portal allows for on demand quoting of coolers and looking up order status
- Custom designs are available
* To register for XSelector® please go to www.thermaltransfer.com/get-in-touch/ and complete the XSelector® Inquiry form and submit.
Download the XSelector® for both Apple and Android formats by searching for XSelector® in their App Stores. You must first register for XSelector® before using it on mobile devices.
Documents
Brochures
SSC Series
Brochures
Water Cooled HE Accessories
Technical
SSC Technical Information
Service Parts
SSC Series Service Parts
Frequently Asked Questions
It’s an all-316 stainless steel, fixed-tubesheet shell and tube heat exchanger from Thermal Transfer Products for oil-to-water and water-to-water cooling in corrosive or poor-water-quality environments.
When corrosive process fluids, saltwater, or poor-quality cooling water would corrode a standard steel or brass exchanger. Full 316 stainless construction resists that attack and extends service life.
Tubes, tubesheets, shell, shell connections, baffles, and end bonnets are all 316/316L stainless steel. Mounting brackets are mild steel with a 316 stainless option.
Same fixed-tubesheet, bare-tube design. The HC is the standard steel/brass workhorse; the SSC is the all-316-stainless version for corrosive service. Choose HC for general duty, SSC for aggressive fluids or bad water.
Maximum shell-side pressure is 300 PSI, tube-side 150 PSI, and maximum operating temperature 300°F.
Yes — the SSC is a drop-in replacement for BASCO Series “500S” stainless steel units. Optional zinc anodes are available for added corrosion protection.
